Startup guide

Diagram of front and rear view showing each part by number. On the front view, upper left, 1. Right side, from top to bottom, 2 and 3. Bottom side, 4. On the rear view, center, 5.

  1. Charging/Notification light
  2. Volume/Zoom key
  3. Power key ()/Fingerprint sensor
  4. USB Type-C™ port/Charger
  5. NFC

To insert SIM and memory cards

Diagram of inserting a SIM card and a memory card into the slots. Right side in rear view, drag out the memory card tray attached to the lid, and drag out the SIM card tray from the lower slot. Place the SIM card and memory card on the trays.

  1. Drag out the SIM and memory card trays.
  2. Place the SIM card securely in the SIM card tray.
  3. Place the memory card securely in the memory card tray.
  4. Gently push the trays back into the slots until they fit into place.

To turn on your device

  1. Long press the power key () until the device vibrates.
  2. Wait a moment for the device to start.

To activate the screen

  • Briefly press the power key ().

Transferring content

For transferring content from an old device to your new device, log in with your Google account and sync your data using services provided by Google. For details visit https://support.google.com.

For more information

Visit support.sonymobile.com.

To view the CE marking and the FCC ID

Diagram of viewing the CE marking on the label strip dragged out from the rear view, right side.

  1. Drag out the memory card tray.
  2. Drag out the label strip in the same way.
  3. To view the FCC ID, turn over your device. The FCC ID is displayed on the other side of the label strip.


Supported frequency bands

J3173

GSM/GPRS/EDGE 850, 900, 1800, 1900MHz. UMTS HSPA+(Bands 1, 4, 5, 8). LTE (Bands 1, 3, 4, 5, 8, 12, 17, 18, 19, 26, 38, 41). WLAN 2.4G/5G, NFC

GSM 850/900 : 33dBm, DCS (1800)/PCS (1900) : 30dBm, UMTS : 24dBm, LTE : 23dBm, 2.4GHz<100mW, 5.15-5.35GHz<200mW, 5.47-5.725GHz<200mW, 5.735-5.835GHz<25mW, NFC 13.56MHz

Loudness warning

To prevent possible hearing damage, do not listen at high volume levels for long periods.

Legal information

This Startup guide is published by Sony Mobile Communications Inc. or its local affiliated company, without any warranty. Improvements and changes to this Startup guide necessitated by typographical errors, inaccuracies of current information, or improvements to programs and/or equipment, may be made by Sony Mobile Communications Inc. at any time and without notice. Such changes will, however, be incorporated into new editions of this Startup guide. All illustrations are for illustration only and may not accurately depict the actual device.

All product and company names mentioned herein are the trademarks or registered trademarks of their respective owners. Any rights not expressly granted herein are reserved. Visit www.sonymobile.com/legal/ for more information.

Manufacturer: Sony Mobile Communications Inc., 4-12-3 Higashi-Shinagawa, Shinagawa-ku, Tokyo 140-0002, Japan. For EU product compliance: Sony Belgium, bijkantoor van Sony Europe B.V., Da Vincilaan 7-D1, 1930 Zaventem, Belgium.

©2019 Sony Mobile Communications Inc.
